The VMF Reactor is a vertical reciprocating motion type next-generation reciprocating mixer for cell culture that combines together excellent blending performance and gentle mixing. Unlike the general rotating type, severe shear stress control is possible. Moreover, a “completely enclosed structure” that does not require a complex rotating-axis seal mechanism is implemented. There is no threat of contamination or leakage, and it has a high level of sterility and cleanliness. A dedicated controller “S-BOX × 10 αⅡ ”which can control DO,pH is provided. Moreover analog singnals can be input to data logger and record them. Through customization, up to eight machines in series are supported.

The MRF Reactor is a BioReactor for laboratory use that aim at actual production and scaling up. In addition to a “Simple shape with excellent cleaning ability” that is important for the actual equipment, the “MR210Bio impeller used exclusively for cell culture” that exhibits excellent mixing and homogenizing performance is provided as a standard, and therefore, similar culture results as during laboratory experiments can be reproduced during scale-up too. Moreover, ? uid surface ? uctuation (fed-batch culture) is supported, because of which the same mixing performance is exhibited no matter how much the liquid volume. A wide range of liquid volumes from small volumes like 1.5 L to large volumes of 20,000 L can be supported. A dedicated controller “S-BOX × 10 αⅡ” which can control DO,pH is

The HSF Reactor is a jar fermenter designed for comparatively low-viscosity microbe cultures, plant cell cultures, fungal-based cultures with high viscosity that show non-Newtonian properties, E. coli cultures, etc., in which target cells and bacterial cells have a comparatively strong shear factor, and cultures that require high OTR. It comes with the high-e? ciency turbine HS100 and high-discharge axial ? ow impeller HR100 as a standard. Optimization is possible for scaling up to large-capacity tasks when paired with the S-BOX series controller for culture control. An optional cooling chiller can be attached, and when using a heat transfer coil type similar to the actual machine, you can achieve conditions that are closer to the actual machine.
